We are proud to announce the release of our new TDP adjustable camber arms. We have invested a massive number of hours on the R & D and the sourcing of all the right grades of materials and rod ends (rose joints).
Our new Rear Top Camber Arms will fit Nissan S14/S15 & R33/R34. They may also fit S13 & R32 depending on the coil-overs. Please contact us for further information.
The adjustment range is 0mm (same as std.) to 50mm longer to reduce negative camber on cars lowered 100+mm.
Each kit will consist of:
2 aerospace quality billet camber arms CNC machined to 0.01mm accuracy and inspected by CMM (co-ordinate measuring machine).
2 In-situe adjusters made from high tensile aerospace stainless steel with lock nuts made of same material.
2 Fluro 16mm Rod Ends with high dynamic load bearing material. With lock nuts made from high tensile aerospace stainless steel.
2 Reducers with 12mm holes to fit & space the rose joints on the frame.
2 M12 high tensile bolts (12.9 grade) & M12 Nylock nuts for the hub end with washers.
2 M12 high tensile bolts (12.9 grade) & M12 Nylock nuts and special stainless steel washers to remove the original Nissan camber adjustment.
Here are some Images to whet you appetite!
Billet of Aluminium 6086 Heat Treated and Tempered to T651
After first stage high speed milling.
A left and right pair after first stage milling and 5 axis milling and threading.
A pair of finished arms with hardware.
As you can see the angle on the in-situe adjuster and rod end gives extra clearance on the chassis legs for exceptionally low cars.
Now fitted to an S14 running pretty low. The chassis to adjuster / rod end clearance is massive. This allows the car to be lowered more than any other camber arm currently on the market.
As you can see the clearance between the damper and camber arm is massive.
Availability NOW.
Warranty
As this is a Motorsport part we won’t warranty crash damage but will warranty the adjuster and rod end against wear for 12 months as long as it has been installed and maintained in accordance with the fitting instructions. All parts will be available separately in case of accidental damage by the user.
Dispatch Time: 3-5 days from order and payment processing. ( Depending on stock levels )
Delivery method: An Post next day in Ireland or DPD to Ireland, Northern Ireland and the UK. Fed-EX and UPS world wide.
Payment method: Cash, PayPal, Major Credit cards, Direct Bank Transfer.
The cost reflects the quality € 195.00 per pair exc vat.
Trade inquiries welcome.
Contact Information
E-mail [email]parts@tdp.ie[/email]
Phone 0404 62650 9:30am 5:30pm Monday to Friday.
